Wednesday, September 21, 2016

Narcissus Restoration Update - Mid-September 2016

Thornton Academy Residential Life student volunteers wire brush the
iron carlynes prior to painting with rust inhibitor primer. The remaining
ash wood roof ribs will be removed, assessed, replaced or repaired,
sanded, primed, stained/painted, and reinstalled. PWM
Narcissus with most of the ash wood roof ribs removed. PWM

Thornton Academy Residential Life student volunteers removing nails,
and preparing ash roof ribs for sanding and repairs. PWM


Donald Curry, lead restoration technician for the Narcissus restoration,
is measuring the "bow" in each of the ash wood roof ribs. Some have
become too "flat" and may not be reused. The weight of the two
trolley pole bases flattened some ribs too much to reuse, and perhaps
when a camp over 30 years, snow accumulation caused other roof
ribs to flatten too much? When the time comes, new ash ribs
will be cut and steam-bent to the proper bow to replace the flattened
or unrepairable ribs. PWM

Each end of each ash roof rib was stamped
with markings when removed. These
markings identify the rib number and which
end was on the left/right side of the roof.
There are more than sixty ribs. Here
you see the nail holes that will be filled and
sanded prior to the top being primed and
sides and bottom being stained. PWM


A few of the ash wood roof ribs waiting to have the repaired nail
holes sanded. You can see the ID letters/numbers on these ribs by
looking near the screw holes. PWM


Ash wood roof ribs after repairs and sanding. PWM


Roof ribs, each with their "bow"
measurement. You may notice an end or two
that has not been sanded. These were left
as found, and will be documented as such,
in the archival record of the Narcissus.
PWM


Ribs prior to receiving stain/primer.
PWM


Stained portion of some ribs. PWM


The gray primer has been applied to the ends and tops of the ribs. The ends
are exposed to the elements and will be painted the same color as the exterior
of the Narcissus, Pullman Green. The tops will accept the nails when the roof
boards are reattached. PWM

Volunteer Jim Mackell making the "blanks" of extensions necessary to replace
those that are missing on the Narcissus. DGC


When finished, each of these blanks will extend from the tops of the
exterior poplar arches that hold the  mahogany sash of the leaded
stained glass windows above the passenger windows. These blanks
were cut from vintage poplar that was recovered by
Rousseau Reclaimed Lumber from a "bank barn" that was razed
in Akorn, PA See image below. PWM

You can see how one extends from the top of the arch to the right. There is
also one that extends from the top left of the arch as well. Each extension,
similar to each arch, has a series of complicated cuts. One cut that allows for
the back top edge to fit behind the large letter board. One cut that allows to
meet and accept the extension next to it. One cut to accept the vertical
sheathing that fits between the arch and the extension (see above as darker
boards that become shorter as they approach the top of the arch). One cut to
accept and blend into the top of the arch. PWM

Thornton Academy Residential Life student volunteers sanding roof boards.
Vintage poplar will be used to make the tongue and groove roof boards to
replace any missing or unusable roof boards. See below
PWM


Volunteers, Jim Mackell and Dick Avy are "grooving"
the vintage poplar for tongue and groove roof boards.
DGC

The Narcissus has about half of the original interlocking tiles in place
down the center of the passenger compartment. There is also
a significant amount of the original tiles in the smoking compartment.
Thornton Academy Residential Life student volunteers are vacuuming
the floor, prior to applying layers of materials to the tile to protect it
from foot traffic. PWM

A sheet of plexiglass is in place so that the
tile can be seen. PWM

The Narcissus tile has a neat history. See below PWM

The tile was patented in 1894 by Frank Furness.
Research done by Donald Curry




Thornton Academy Residential Life student volunteers staff a Narcissus
project table at Seashore Trolley Museum's Members' Day event. PWM

Thornton Academy Residential Life student volunteers enjoy a ride
on the 1907 Twin City Rapid Transit No. 1267. PWM


From the Twin City Rapid Transit, Thornton Academy Residential Life
student volunteers will transfer to the 1914 Cleveland Railway No. 1227.
PWM


Thornton Academy Residential Life student volunteers enjoy a ride on
the 1914 Cleveland Railway No. 1227.
PWM


Seashore Trolley Museum volunteer operator, John Middleton, is
91 years old, and is explaining to two of the Thornton Academy Residential
Life
student volunteers, that during his working career, he was an aerospace
engineer
(I like to say John is a rocket scientist :) and
designed testing equipment that landed safely on the surface of the moon!
This life lesson is teaching that volunteers at the Trolley Museum come
with a wide variety of professional skills. PWM

Volunteer John Middleton operating the 1901 Connecticut Company open
car No. 303 as Thornton Academy Residential Life student volunteers enjoy a
ride to the Pumpkin Patch.
PWM


Thornton Academy Residential Life student volunteers enjoy a
ride on the 1901 Connecticut Company open car No. 303. PWM


Ad in Classic Trains Magazine 8-2016
PWM
Ad in Trains Magazine 8-2016
PWM
